Littelfuse HWB Series PDMs
MXP120 Sealed Connectors by Molex
Trombetta Battery Separators
Connector, 6 Position Plug Assembly
AMPSEAL 16 Connectors are targeted for off-road, heavy-duty industrial, recreational and agricultural applications. The connectors offer rugged reliability, easy use, and help prevent moisture and dirt from contaminating connections.
  • TE Connectivity 776433-1 AMPSEAL 16 Connector, 6 Position Plug Assembly
  • Category: AMPSEAL 16 Connectors
  • Manufacturer: TE Connectivity
  • Integrated Primary Latch Reinforcement (PLR) confirms contact alignment and retention
  • Accepts contact size HDSF 16 (up to 13A)
  • Wire Gauge Range:14-20 AWG (2.50-0.50 mm2)
  • Number of Positions: 6
  • PLR Color: Red
  • Housing: Female HDSF Terminals
  • Current: up to 13A
  • Operating Temperature:-40C to +125C
  • Immersion: IP67
  • Voltage: 250V
1.8150
EACH
This function is not yet complete
Resistor & Bracket, 896H-1CH-D1SW-R1-24VDC
  • Song Chuan High Power Skirted Mini Relay, SPDT w/ Resistor & Bracket
  • Category: Mechanical Relays & Connectors
  • Manufacturer: Song Chuan
  • Component Type: Mini Relay
  • Contact Action: SPDT
  • NO Amp: 20A
  • NC Amp: 15A
  • Volt Rating: 24V
  • Relay Contact Form: 1 Form C (SPDT-NO, NC)
  • Terminals: Five 1/4" Terminals
  • Resistor & Bracket included
  • Space saving relay with high current capacity
  • Designed to perform in temperatures as low as -40F (-40°C) and as high as 275F (125°C)
  • Ideal for use in a variety of automotive applications including starter motors, hazard-warning lights, ignition and battery disconnect relays, etc.
5.0090
EACH
This function is not yet complete
Cartridge Fuse, 25A, 32V, Time Delay
The Unslotted MCASE+ Fuse is a cartridge style fuse up to 40A with female terminals for 2.8mm male terminals. The Slotted MCASE+ Fuse is available in amperage's up to 60A and can mate with larger male terminals (e.g., 6.3mm) or even mount directly onto a busbar.
  • Littelfuse 0695025.PXPS Slotted MCASE+ Cartridge Fuse
  • Category: Fuses
  • Manufacturer: Littelfuse
  • Series: MCASE+ Fuses
  • Style: Cartridge Fuse
  • Voltage Rating: 32V
  • Current Rating: 25A
  • Miniaturized footprint for optimal usage of space
  • Handles inrush currents
  • Conforms to SAE
0.6850
EACH
This function is not yet complete
6 Circuits with Negative Bus and Cover
Packaged for retail use only. For bulk product, see item 78152B (must be logged in to purchase bulk)
  • Blue Sea Systems 5025 ST Blade Fuse Block
  • Category: Fuse Holders
  • Manufacturer: Blue Sea Systems
  • Positive distribution bus with #10-32 stud
  • Can be used for 24-hour circuits
  • Tin-plated copper buses and fuse clips
50.9900
EACH
This function is not yet complete
Power Distribution Module, 200A
  • EATON's Bussmann Series 31S-000-0 ssVEC Power Distribution Module
  • Category: Power Distribution Modules
  • Manufacturer: EATON
  • Max Rating: 200A
  • This pre-populated module features an 8 relay plus 8 fuse configuration
    • Custom configurations available: Maximum 12 relays / 32 fuses, or various combinations thereof - please call us
  • Operating Temperature: -40c to 85c
  • Weathertight
  • Severe Service Vehicle Electrical Center (ssVEC) parts included:
    • 3 - 10amp ATM mini fuse
    • 3 - 15amp ATM mini fuse
    • 3 - 20amp ATM mini fuse
    • 3 - 30amp ATM mini fuse
    • 8 - ISO 280 Micro Relay with Resistor
      • NO Amp: 35A
      • NC Amp: 20A
      • Volt Rating: 12V
    • 1 - fuse puller
  • For Power Distribution Connectors, correspond with below parts:
146.6220
EACH
This function is not yet complete
Distribution Module, Pre-populated, 300A
  • Littelfuse FLEC3000Z-0 Configurable Power Distribution Module
  • Category: Power Distribution Modules
  • Manufacturer: Littelfuse
  • Volt Rating: 12 or 24V DC
  • Max Load: 300A
  • Max Fuse Rating: 30A
  • Fuse Capacity: 28 MINI style
  • Relay Capacity: 18 ISO style
  • Operating Temp: -40 to +85C
  • Vibration Resistance: ISO 16750-3 Test II, 32 Hours
  • Shock Resistance: ISO 16750-3, Section 4.2.2
  • Output Connectors: Delphi GT Series
  • FLEC maximizes available space and limits the number of additional units required
  • The versatile nature of the FLEC unit means it can accept a large number of component types. MINI, ATO, MAXI, JCASE, MCASE, and ISO components are all accepted
  • Rugged and sealed, the unit boasts an IP67 rating which allows it to be mounted in locations susceptible to moisture and dirt without any adverse effects
  • Input stud caps prevent accidental short circuit while performing maintenance to and around the box
  • Reduced risk of wiring faults: the FLEC uses highly reliable printed circuit board
  • Note: FLEC can be custom designed. Contact Waytek sales for details
  • FLEC parts included:
    • 6 - 15A MINI Fuse
    • 22 - 30A MINI Fuse
    • 18 - ISO 280 Micro Relay with Resistor
      • NO Amp: 35A
      • NC Amp: 20A
      • Volt Rating: 12V
    • 2 - Spare 15A MINI Fuse
    • 2 - Spare 30A MINI Fuse
    • 1 - Fuse Puller
  • Power Distribution Connectors Correspond with below parts:
    • J4 Connection - GT280 14-way 38391
    • J5 Connection - GT150 16-way 38337
    • J6 Connection - GT150 10-way 38333
    • J7 Connection - GT150 12-way 38335
    • J8 Connection - GT280  8-way  38382
    • J9 Connection - GT280 16-way 38388
377.4860
EACH
This function is not yet complete
Qty Item #
get a quote
Online Quotes looking for pricing on quantities larger than what's listed? Request a large quantity quote.
