Eaton's Bussmann Series 25525-B-2 Mid-Range Circuit Breaker, Type III Reset, 25A, 32VDC
Waytek #:46973
Mfr. #:25525-B-2
$30.8900 / EA
Price Break per EA
| Qty | Ea. Price | Ext. Price |
|---|---|---|
| 1 | $30.8900 | $30.89 |
| 5 | $27.6500 | $138.25 |
| 10 | $25.8100 | $258.10 |
| 50 | $24.2600 | $1,213.00 |
| 100 | $23.1300 | $2,313.00 |
| 200 | $22.0000 | $4,400.00 |
Price Break per EA
| Qty | Ea. Price | Ext. Price |
|---|---|---|
| 1 | $30.8900 | $30.89 |
| 5 | $27.6500 | $138.25 |
Min. Order Qty: 1 |
Availability: 0 in Stock |
Standard Lead Time When No Stock: 88 days |
Documents
- Eaton's Bussmann Series 25525-B-2 Mid-Range Circuit Breaker
- Category: Eaton's Bussmann Series Mid-Range Circuit Breakers
- Manufacturer: Eaton
- Series: 25X
- Type: Mid-Range Circuit Breaker
- Reset Method: Type III - PTT (Push to Trip)
- Mounting Holes: #8-32 threaded inserts
- Material: UL-Rated 94V0 thermoplastic body, cover, and button
- External ignition protected and weatherproof
- Reset mechanism provides visual indication of tripped condition
- Typically used in DC power systems in:
- Marine applications (main or branch circuit breaker)
- Trucks
- Bus & RV systems
- Also seen as CB255-25
- IP66 rated, ABYC E11
- Single pole thermal type
- Manual trip feature allows opening of the circuit path without disconnection from the power source
- Panel mount design available in two styles: automatic reset or switchable with manual trip push button
- SAE J553; J1171
- -40°F (-40°C) - 185°F (85°C)
Manufacturer : Eaton
Current Rating: 25A
Mounting Style: Panel Mount
Reset Method: Type III - Switchable Reset
Series: Series 25X
Termination: #10-32 Threaded Stud
Country of Origin: Mexico
